XZ450 450KN.M Horizontal Directional Drill Machine for sale

FOB Reference Price:Get Latest Price
$50,000.00 - $100,000.00 / Sets | 1 Set/Sets (Min. Order)
Model Number:
XZ450
Lead Time:
Quantity(Sets) 1 - 1 >1
Est. Time(days) 15 Negotiable
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Jiangsu, China
After-sales Service Provided:
Engineers available to service machinery overseas
Power:
194kw/2200
Max.pullback/thrusting:
160/100 kN
Spindle torque(max):
5000 N.m
Mud flow rate(max):
160
Dimension(L*W*H):
11000x2800x3300
Engine Model:
QSC8.3-C260
Supply Ability
Supply Ability:
10 Set/Sets per Month
Packaging & Delivery
Packaging Details
nude packing
Port
Shanghai port
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 15 To be negotiated
Product Description

Conatct Person: Adela

 Whatsapp:+86-158 0095 4269

 Email: adela @evangelchina.com







XZ450 horizontal directional drilling rig machine



Pluralities of advanced control technologies are adopted, including the PLC control, electro-hydraulic proportion control, load sensitive control, etc.



The drilling rod automatic disassembly and assembly device can improve the working efficiency, relieves the labor intensity and manual error operation of the operators, and reduces the construction personnel and the construction cost.



                XZ450 HORIZONTAL DIRECTIONAL DRILL

                                             ITEM

                  PARAMETER

Engine

Make

Cum

Model

QSC8.3-C260

Rated Power

194 KW / 2200 R/Min

Operation

Type

Rack and pinion

Max. Thrust /Pullback Force

480/480 KN

Max carriage thrust/pullback travel speed

42M/Min

Max. Spindle Torque

23500 N·M

Max. Spindle Speed

135R/Min

Type

Self-Propelled Steel Track

Ground Travel Speed

3.0 Km/h

Drill Rod/ Drill pipe

Diameter ×Length

Φ89 mm×4500mm

Entry Angle

10~20°

Mud Pump

Max flow rate

600L/Min

Max pressure

10

Overall Weight

13.3T

Overall Dimension

8800×2280×2610mm
