Truck Crane 25 ton QY25K-II Chinese Pickup Small Truck Mobile Crane With Price

FOB Reference Price:Get Latest Price
$85,000.00 - $93,000.00 / Sets | 1 Set/Sets (Min. Order)
Max. Lifting Load:
25T
Model Number:
QY25K-II
Report Suspicious Activity
Overview
Quick Details
Max. Lifting Height:
34.19m
Warranty:
1 Year
After-sales Service Provided:
Field installation, commissioning and training, Field maintenance and repair service, Video technical support, Online support
Feature:
Truck Crane
Condition:
New
Application:
Construction
Rated Loading Capacity:
23200kg
Rated Lifting Moment:
1010KN.M
Span:
5.14m
Place of Origin:
Jiangsu, China
Certification:
CE
Color:
Yellow
Dead weight in travel state:
29400kg
Engine Model:
SC8DK280Q3/WD615.329
Engine rated output(kw/rpm):
206/2200, 213/2200
Max.Travel Speed:
75km/h
Boom Elevating Time:
75s
Boom Full Elevating Time:
100s
Max.Gradeability:
30%
Max.Slewing Speed:
2.5rpm
Overall Dimensions:
12650mm*2500*3380mm
Supply Ability
Supply Ability:
10 Set/Sets per Month
Packaging & Delivery
Packaging Details
Ro-Ro Shipment or Bulk Break
Port
shanghai, Qingdao,Ningbo,Tianjin



Contact Person: Adela Huang



Mobile:+86-15800954269 (whatsapp/Viber)



Wechat:+86-15800954269



Email: adela @ evangelchina.com



Product Description

Truck Crane 25 ton QY25K-II Chinese Pickup Small Truck Mobile Crane With Price



Parameters:

Dimension

Unit

QY25K-II

Overall length

mm

12650

Overall width

mm

2500

Overall height

mm

3380

Weight



Total weight in travel

kg

29400

Front axle load

kg

6200

Rear axle load

kg

23200

Power



Engine model



SC8DK280Q3 / WD615.329

Engine rated power

kW/(r/min)

206/2200   213/2200

Engine rated torque

N.m/(r/min)

1112/1400  1160/1400

Travel



Max. travel speed

km/h

75

Min. turning diameter

m

21.5

Min. ground clearance

mm

275

Approach angle

°

16

Departure angle

°

13

Max. grade ability

%

30

Fuel consumption for 100km

L

≈37

Main performance



Max. rated total lifting capacity

t

25

Min. rated working radius

mm

3000

Turning radius at turntable tail

m

3.065

Max. lifting torque

kN.m

1010

Base boom

m

10.7

Fully extended boom

m

34.19

Fully extended boom+jib

m

42.15

Longitudinal outrigger span

m

5.14

Lateral outrigger span

m

6

Working speed



Boom luffing time

s

75

Boom full extension time

s

100

Max. swing speed

r/min

≥2.5

Max. speed of main winch

m/min

≥120

Max. speed of aux. winch

m/min

≥120
